Mini Digital Video CMOS 1000TVL FPV Camera and 5.8

5.8G Double Screen Display 600mW FPV Audio Video Transmitter
Video Format: NTSC/PAL
Output Impedance: 50 Ohm
Transmitter frequency range: 5645-5945MHz
Transmitting distance:3000m (open area)
Antenna connector: RP-SMA connector
Operating Voltage: 7-24 V
Output Voltage (VOUT): 5 V
Supply current: 280 mA
Operating Temperature: -10 +85 C
Video Band Width: 0-8.0 MHz
Audio carrier Frequency: 6.5 MHz
Video Input Level: 0.8,1.0,1.2 Vp-p
Video Input Impedance: 75 Ohm
Audio Input Level: 0.5 ,2.0 Vp-p
Audio Input Impedance: 10K Ohm
Weight: 15g
FPV Mini Digital Video 1000TVL 2.8mm Camera
Lens focal length: 2.8mm
Singal system: PAL/NTSC system
Horizontal Articulation: 1000TVL
Min Illumination: 0.01LUX
White Balance: Auto
Video Frame Rate: PAL:967H x 582V, NTSC: 976H x 494V
Video Output: 1.0Vp-p75 ohm
Electronic Shutter: 1/50(1/60)-1/100000s
Back Light Compensation: ON/OFF
Synchronization: Inter-sync
Power input: DC5-12V
Power Consumption: 70mA
Openration Tempetature: -20–60 (0-98)
Size: 24 x 17 x 28mm/0.9 x 0.7 x 1.1 inch
Package size: 90 x 65 x 55mm/ 3.5 x 2.6 x 2.2 inch
Net weight: 14g
Package weight: 39g
