10Kohm 103 Trimpot Trimmer Potentiometer

Passive components 5 piece 10K ohm 3296w-103 cermet adjustable resistance
10K Ohm Through Hole 3296 Trim Pot Trimmer Potentiometer 5 Pcs
Product Name: Cermet Potentiometer;
Model: 3296-103; Withstand Voltage: 500V; Rated Power : 1/2W
Resistance Value: 10K Ohm; Tolerance: +/-10%;Adjustment Type : Top Adjustment ;Mounting Type : Through Hole(DIP)
Turn Number: 25; Resistance Change Type : Linear;
Temperature Coefficient: +/-100ppm/Celsius
Total Length: 18mm/ 5/8
Resistive Material: Cermet
Body Size: 9 x 9mm/ 3/8 x 3/8 (L*W)
Color: As Picture Shown
Weight: 5g/1pcs
Feature:10K Ohm three-terminal resistor with a continuously adjustable tapping point controlled by rotation of a shaft or knob.
